FlameGuardä is comprehensive product line of fiberglass, silica and silicone rubber coated fiberglass industrial sleeve, tape and fabric; the ideal choice to protect industrial and commercial hoses, cables, wiring & equipment from heat, flame, molten splash, welding splatter, sparks and environmental factors such as contamination, Ozone, UV light and abrasion.
FlameGuardä products are the ideal materials to protect workers and personnel from hot or cold pipes and hoses, such as oil cooler lines, steam tracers, refrigeration lines, etc.
Main FlameGuardä Product Lines:
FlameGuardä products are the ideal materials to protect workers and personnel from hot or cold pipes and hoses, such as oil cooler lines, steam tracers, refrigeration lines, etc.
Main FlameGuardä Product Lines:
FlameGuardä SR products withstand 550°F / 287°C continuous exposure;
2200°F / 1205°C for periods up to 15 minutes and 3000°F / 1650°C for short durations.
· FlameGuardä SR Sleeve, Heavy Duty Sleeve, VC Sleeve, Tape & Fabric provides
approximately R2 insulation value per layer.
· Minimum dielectric breakdown per layer of FlameGuardä SR Sleeve, Heavy Duty
Sleeve, VC Sleeve, Tape and Shield Fabric is 5 kV, with a sample average of 8 kV.
Minimum dielectric breakdown per layer of End Wrap Tape is 8 kV.
FlameGuardä SR Rope has not been tested.
2200°F / 1205°C for periods up to 15 minutes and 3000°F / 1650°C for short durations.
· FlameGuardä SR Sleeve, Heavy Duty Sleeve, VC Sleeve, Tape & Fabric provides
approximately R2 insulation value per layer.
· Minimum dielectric breakdown per layer of FlameGuardä SR Sleeve, Heavy Duty
Sleeve, VC Sleeve, Tape and Shield Fabric is 5 kV, with a sample average of 8 kV.
Minimum dielectric breakdown per layer of End Wrap Tape is 8 kV.
FlameGuardä SR Rope has not been tested.
Sleeve
Tape
Fabric
VC Sleeve
Rope
End Wrap Tape
500 SR - High Temperature Silicone Rubber Coated Fiberglass:
Available in 6 styles:
SR Sleeve is manufactured in a Standard grade from E-type knitted glass fiber, while
Heavy Duty grade is made with a thicker and denser braided inner glass fiber material.
Aero Grade sleeve meets AS1072 so that aviation hose assemblies can pass AS1055D testing.
SR Tape is manufactured from a knitted E-type fiberglass.
SR Fabric is a heavy-weight braided fabric with an extra thick coating of silicone rubber.
SR VC Sleeve is a sleeve manufactured from our fabric using Velcro® hook-and-Loop
fastener - ideal for retrofit installations.
SR Rope is ideal as an airtight gasket or seal on industrial oven and kiln doors.
SR End Wrap Tape is used to seal the ends of FlameGuardä Sleeve installed over
hydraulic hose or electric cables, providing a liquid-tight installation.
SR ThermaSealä Liquid is a liquid silicone that can be brushed or dipped to seal the
ends of FlameGuardä Sleeve installed over hydraulic hose or electric cables, providing a
liquid-tight installation and preventing end-fray.
FlameGuardä SR Products protects both equipment and personnel while providing
electrical & thermal insulation value.
Available in 6 styles:
SR Sleeve is manufactured in a Standard grade from E-type knitted glass fiber, while
Heavy Duty grade is made with a thicker and denser braided inner glass fiber material.
Aero Grade sleeve meets AS1072 so that aviation hose assemblies can pass AS1055D testing.
SR Tape is manufactured from a knitted E-type fiberglass.
SR Fabric is a heavy-weight braided fabric with an extra thick coating of silicone rubber.
SR VC Sleeve is a sleeve manufactured from our fabric using Velcro® hook-and-Loop
fastener - ideal for retrofit installations.
SR Rope is ideal as an airtight gasket or seal on industrial oven and kiln doors.
SR End Wrap Tape is used to seal the ends of FlameGuardä Sleeve installed over
hydraulic hose or electric cables, providing a liquid-tight installation.
SR ThermaSealä Liquid is a liquid silicone that can be brushed or dipped to seal the
ends of FlameGuardä Sleeve installed over hydraulic hose or electric cables, providing a
liquid-tight installation and preventing end-fray.
FlameGuardä SR Products protects both equipment and personnel while providing
electrical & thermal insulation value.
FlameGuard
ä
The Ultimate Flexible Protective Sleeve, Tape and Fabricä
AB Technology Group
11 Cotton Street., Bowmanville, ON L1C 5H3
Tel: 905-448-3528 Fax: 610-340-9054
11 Cotton Street., Bowmanville, ON L1C 5H3
Tel: 905-448-3528 Fax: 610-340-9054
Latest Catalog is Jan 2011
We also ship from our warehouse in Watertown NY
FlameGuardä 500 SR Products
Silicone Rubber Coated Fiberglass
Silicone Rubber Coated Fiberglass
FlameGuardä 1000 Products
Fiberglass Based
Fiberglass Based
FlameGuardä 2000 Products
Silica Based
Silica Based
Sleeve
Tape
Rope
Fabric
Insulation
FlameGuardä 1500 Products
Vermiculite Coated Fiberglass
Vermiculite Coated Fiberglass
Sleeve
Tape
Fabric
Rope
Insulation
Sleeve
Tape
Fabric
Rope
Insulation
FlameGuardä 2300 Products
Ceramic Fiber Based
Ceramic Fiber Based
Tape
Fabric
Rope
Insulation
Paper
FlameGuardä 550 PT Products
PTFE (teflon) Coated
PTFE (teflon) Coated
Tape
Sleeve
Rope
Fabric
1000 FB - Very High Temperature Fiberglass: Premium & Industrial
Available in 5 products:
Sleeve is manufactured in an E-type knitted or braided glass fiber.
Tape is manufactured from a knitted or woven E-type fiberglass.
Rope is ideal as an airtight gasket or seal on industrial oven and kiln doors.
Fabric is available in 6 thicknesses and 2 roll widths.
Insulation is available in 3 thicknesses for use in curtains and blankets.
Available in 5 products:
Sleeve is manufactured in an E-type knitted or braided glass fiber.
Tape is manufactured from a knitted or woven E-type fiberglass.
Rope is ideal as an airtight gasket or seal on industrial oven and kiln doors.
Fabric is available in 6 thicknesses and 2 roll widths.
Insulation is available in 3 thicknesses for use in curtains and blankets.
1500 VB - Very High Temperature Vermiculite Coated Fiberglass:
Same Specifications as the FlameGuardä 1000 Very High Temperature Fiberglass but with the addition of vermiculite. Available in 4 products:
Sleeve - Tape - Rope - Fabric
Same Specifications as the FlameGuardä 1000 Very High Temperature Fiberglass but with the addition of vermiculite. Available in 4 products:
Sleeve - Tape - Rope - Fabric
2000 - Extreme High Temperature Silica
Silica fibers (SiO2) provide enhanced thermal capability. Available in 5 products:
Sleeve - Tape - Rope - Fabric - Insulation
Silica fibers (SiO2) provide enhanced thermal capability. Available in 5 products:
Sleeve - Tape - Rope - Fabric - Insulation
2300 - Extreme High Temperature +Plus Ceramic Fiber
Ceramic fiber is a mixture of alumino-silicate (AL2O3) and silica (SiO2) and is often mixed with a re-inforcement carrier such as fiberglass or stainless steel or inconel.
Available in 5 products:
Paper - Tape - Rope - Fabric - Insulation
Ceramic fiber is a mixture of alumino-silicate (AL2O3) and silica (SiO2) and is often mixed with a re-inforcement carrier such as fiberglass or stainless steel or inconel.
Available in 5 products:
Paper - Tape - Rope - Fabric - Insulation
FlameGuardä HHP31
Asbestos Replacement Fabric
Asbestos Replacement Fabric
FlameGuardä Graphite Coated
FlameGuardä Tadpole Gaskets
450 RP - Radiant Heat Protection
Provides excellent protection from radiant heat sources. Available as a sleeve or as a fabric:
RP Sleeve is manufactured from RP fabric in standard and custom sizes.
RP Fabric is available in two widths.
Provides excellent protection from radiant heat sources. Available as a sleeve or as a fabric:
RP Sleeve is manufactured from RP fabric in standard and custom sizes.
RP Fabric is available in two widths.
FlameGuardä 550
Radiant Heat Protection
Radiant Heat Protection
Tadpole Gaskets
550 - PTFE High Temperature & Chemical Resistance
Fiberglass base materials coated with PTFE (Teflon) offer high temperature resistance and exceptional chemical resistance.
Available in 4 products:
Sleeve - Tape - Rope - Fabric
Fiberglass base materials coated with PTFE (Teflon) offer high temperature resistance and exceptional chemical resistance.
Available in 4 products:
Sleeve - Tape - Rope - Fabric
HHP31 - Asbestos Replacement Fabric - Certified Specification
Fiberglass base material which is made with an interwoven stainless steel wire. Meets HHP31-F-TY1 specification and is available certified.
Fiberglass base material which is made with an interwoven stainless steel wire. Meets HHP31-F-TY1 specification and is available certified.
1000 GC Very High Temperature with Graphite Coating
Fiberglass base materials coated with Graphite provides superior lubrication and a surface that molten materials will not stick to. Also provides electrical conductivity.
Available as sleeve and rope
Fiberglass base materials coated with Graphite provides superior lubrication and a surface that molten materials will not stick to. Also provides electrical conductivity.
Available as sleeve and rope
Sleeve
Rope
FlameGuardä Specialty Products
Kiln Seals
High, Very High and Extreme Temperature Tadpole Gaskets
Custom fabricated tadpole gaskets from a variety of materials (fiberglass, silicone coated fiberglass, silica, PTFE coated fiberglass) and bulb fillers (fiberglass, silica, and metal mesh rope).
Custom fabricated tadpole gaskets from a variety of materials (fiberglass, silicone coated fiberglass, silica, PTFE coated fiberglass) and bulb fillers (fiberglass, silica, and metal mesh rope).
High and Very High Temperature Flange and Pipe Gaskets
Custom fabricated from a variety of envelope and filler materials.
Custom fabricated from a variety of envelope and filler materials.
Flange / Pipe Gaskets
Very High & Extreme
Temperature Tadpole Gaskets
Temperature Tadpole Gaskets
Fabric
Fabric
Sleeve
Need to convert units
(metric/imperial)?
(metric/imperial)?
FlameGuardä 2000
Welding Blankets / Curtains / Pads
Welding Blankets / Curtains / Pads
Extreme Temperature Welding Blankets - Curtains - Pads
Fabricated in standard sizes or custom.
Fabricated in standard sizes or custom.
